The Ferroday 30 Plate Wort Chiller serves as a highly efficient tool for homebrewers looking to rapidly cool their boiling wort down to yeast pitching temperatures. Designed with 30 stainless steel plates, this heat exchanger maximizes thermal transfer by utilizing a counter-flow mechanism where hot wort and cold water pass through alternating channels. This compact unit measures approximately 7.3 inches by 2.8 inches, making it a space-saving addition to any brewing setup that does not sacrifice performance for size.
Constructed from durable stainless steel and fully brazed for a leak-proof seal, the Ferroday 30 Plate Wort Chiller is built to withstand the rigors of frequent brewing sessions. The device features 1/2 inch NPT threaded connections, ensuring compatibility with standard hoses and plumbing fittings commonly found in home environments. This robust build quality ensures that the heat exchanger remains sanitary and easy to clean, which is essential for preventing off-flavors and maintaining high standards in your finished beer.
Incorporating the Ferroday 30 Plate Wort Chiller into your brew day significantly reduces cooling time compared to traditional immersion chillers. By shortening the time spent at elevated temperatures, this device helps minimize the production of DMS and promotes better protein coagulation during the chilling process. Whether you are brewing a crisp lager or a heavily hopped IPA, this plate chiller provides the precise temperature control needed to consistently produce professional-grade results from the comfort of your own home.
FEATURES:
– 30 plate design
– Stainless steel construction
– 1/2 inch NPT
– Brazed plate exchanger
– Homebrew wort cooler
– Compact 7.3 x 2.8 size
The Ferroday 30 Plate Wort Chiller offers homebrewers an efficient and reliable solution for cooling boiling wort rapidly after the brewing process. Its compact design features 30 stainless steel plates brazed together to provide a large surface area for effective heat exchange within a small footprint of 7.3 inches by 2.8 inches. By circulating cold water through one side and hot wort through the other, this device facilitates a quick temperature drop that helps stabilize the product and promotes better clarity in the final brew.
– Durable stainless steel construction
– Reduces homebrew oxidation
– Rapid chilling capability
– Compact space saving design
– Compatible with water pumps
– Versatile for multiple applications
– Cannot be dissembled to clean
– Requires filter to prevent clogging
– Cannot be used for viscous liquids
The Ferroday 30 plate wort chiller offers a durable stainless steel construction and a compact, space-saving design that provides rapid chilling capabilities while helping to reduce homebrew oxidation. It is highly compatible with water pumps and versatile enough for various applications, though users should be aware that it cannot be disassembled for cleaning, is restricted to non-viscous liquids, and necessitates the use of a filter to prevent internal clogging. Read more…
Plate Chiller vs. Immersion Chiller Comparison
This image is a promotional graphic comparing a plate wort chiller to an immersion chiller for homebrewing applications. On the left, a compact, rectangular 30-plate heat exchanger is marked with a green checkmark, highlighting benefits such as an adjustable flow rate, prevention of contamination, and avoidance of oxidation. The text claims this device can cool 5 gallons of hot wort in minutes, which is presented as significantly faster and more space-efficient than the immersion chiller shown on the right. The immersion chiller, consisting of a coiled metal tube, is marked with a red ‘X’ and described as taking up to an hour to perform the same task. The overall message emphasizes that the plate chiller is a more effective, time-saving, and economical tool for cooling wort to a safe temperature during the brewing process.
Brazed Plate Wort Chiller Overview
This technical product graphic displays a heavy-duty, 30-plate heat exchanger designed for homebrewing applications. The image highlights a rectangular stainless steel unit featuring four threaded 1/2 NPT ports clearly labeled for ‘Wort In,’ ‘Wort Out,’ ‘Water In,’ and ‘Water Out.’ The unit is constructed from 304 stainless steel with 99.9% brazed metal sheets, offering a wide operating temperature range from -321°F to 392°F and a maximum pressure rating of 145 psi. Accompanying the product image are icons illustrating its ease of maintenance, durable tube construction, and straightforward installation, alongside cautionary text advising against allowing liquids to freeze inside the chiller to prevent structural damage.
Wort Chiller Plate Heat Exchanger
This image displays a compact, stainless steel plate heat exchanger, specifically designed as a wort chiller for homebrewing. The device features a rectangular, stacked-plate design with dimensions of 7.5 inches in length, 2.9 inches in width, and 2.9 inches in height. It is equipped with four connection ports, each labeled for specific fluid flow: ‘Wort Out,’ ‘Wort In,’ ‘Water In,’ and ‘Water Out.’ Two of these ports are fitted with barbed hose adapters, while the other two display exposed 1/2 NPT threaded connections. A central information label provides a cautionary note regarding the prevention of liquid freezing within the chiller to avoid damage to the internal plates, emphasizes the importance of safety when handling hot liquids, and advises users to inspect all connections and consult the instruction manual.
Wort Chiller Plate Heat Exchanger Operation
The image illustrates the functioning of a plate heat exchanger used as a wort chiller for brewing. The primary diagram shows a rectangular, stacked-plate unit with four threaded ports on its top surface. Hot wort enters from a brew kettle into the back-right port and exits as cooled wort from the back-left port, destined for a fermenter. Simultaneously, cold water enters the front-left port and exits as warm water from the front-right port. Text guidelines suggest achieving optimal cooling by maintaining a slow wort flow and a fast water flow. Below the main component, structural schematics detail the internal mechanics, demonstrating how the hot wort and cold water flow in opposing directions through alternating, separated corrugated internal plate channels to facilitate efficient heat transfer without the liquids mixing.
Homebrewing Wort Chilling Setup
This image demonstrates a functional homebrewing setup utilizing a FERRODAY 30-plate wort chiller to rapidly cool beer wort after boiling. The primary photograph shows a large stainless steel brew kettle connected via translucent silicone tubing to the plate chiller, which is positioned on a workbench. The chiller itself features multiple ports for fluid circulation, with a smaller inset circular photo providing a close-up view of a person connecting a quick-disconnect fitting to a hose, illustrating how the system is assembled. A text overlay explicitly warns that the necessary plumbing fittings required to complete this configuration are not included with the purchase of the chiller unit.
Plate Wort Chiller Product Overview
The image displays a compact, stainless steel plate wort chiller designed for homebrewing applications. The device features four threaded ports for hose connections, clearly labeled ‘Wort In,’ ‘Wort Out,’ ‘Water In,’ and ‘Water Out’ to facilitate efficient counter-flow heat exchange. Text overlaid on the image provides essential operational and maintenance instructions, highlighting the importance of screening the wort to prevent clogging and emphasizing safety precautions regarding hot liquids and freezing risks. Additionally, a numbered four-step cleaning protocol is listed, recommending an immediate flush after use, followed by sanitation, rinsing with clean water, and air drying to ensure the device remains in optimal condition.
Plate Wort Chiller
The image features a stainless steel plate wort chiller used in homebrewing to rapidly cool boiling wort. The device is rectangular with a stack of thin, corrugated metal plates that provide a large surface area for heat exchange. Four threaded ports are located on the top face, clearly labeled for ‘Wort Out,’ ‘Wort In,’ ‘Water In,’ and ‘Water Out’ to guide the plumbing of the cooling system. A prominent label on the front provides safety warnings, advising against allowing liquid to freeze inside the unit and emphasizing caution when handling hot liquids. Directly below the chiller are four translucent, light-blue plastic caps intended to protect the threaded ports during storage or transport.
Plate Heat Exchanger
This image displays a compact, stainless steel brazed plate heat exchanger commonly used as a wort chiller in homebrewing. The device features a rectangular body constructed from multiple stacked metal plates. On the front face, a white instructional label is prominently displayed, detailing usage warnings regarding liquid freezing, handling hot liquids, and the necessity of inspecting connections and reading the manual. Four threaded port connections are positioned at the corners, each currently protected by a light blue plastic cap. The design allows for a counter-flow heat exchange process, with labeled inputs and outputs for both the hot wort and the cooling water.
